Product Details
| Basic Information | |
| Usage | Suction-type Sewer Scavenger |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 5900mm |
| Width | 2000mm |
| Height | 2500mm |
| Curb Weight | 4200kg |
| Gross Weight | 8260kg |
| Seats | 2 |
| Max Speed | 90km/h |
| Chassis | |
| Chassis Model | HQG1080GD5 |
| Front/Rear Overhang | 1210/1390,1040/1560,1145/1455mm |
| Number of Leaf Springs | 8/10+7,11/9+7 |
| Number of Axles | 2 |
| Wheelbase | 2800,3300,3600,3800mm |
| Axle Load | 3300/4960kg |
| Front Wheel Track | 1835,1750,1550mm |
| Rear Wheel Track | 1640,1586,1530mm |
| Approaching/Departuring Angle | 19/14° |
| Tire | |
| Number of Tires | 6 |
| Tire | 7.50-16 16PR,7.50R16 16PR |
| Engine | |
| Model | YC4FA100-50,WP3.7Q102E50,CY4BK551,YN33CRE2 |
| Power | 75,75,75,75kW |
| Brand | Guangxi Yuchai Machinery Co., Ltd.; Weichai Power Yangzhou Diesel Engine Co., Ltd.; Dongfeng Chaoyang Diesel Co., Ltd.; Kunming Yunnei Power Co., Ltd. |
| Displacement | 2982,3660,3707,3298ml |
