Working conditions:

Altitude: ≤3,000m

ambient temperature: -20～40℃

Relative humidity: ≤95%

Maximum milling width(mm)：2,100

Milling depth(mm)：0～320

Number of cylinders：6

Rated engine speed(rpm)：2,100

Working speed(m/min): 0～30

Walking speed(km/h): 0～4.5

Climbing capacity (%): 80：

Min ground height(mm): 325

Front axle loading capacity (kg): 20,600

Rear axle loading capacity (kg): 17,200

Dead weight(kg): 32,800

Operating Weight(kg): 37,800

Front caterpillar(mm): 1,995×305×676

Rear caterpillar(mm): 1,995×305×676
