Product Details
| Basic Information | |
| Usage | Recreational Vehicle |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 9355mm |
| Width | 2532mm |
| Height | 3777mm |
| Curb Weight | 13146kg |
| Gross Weight | 13350kg |
| Seats | 3 |
| Max Speed | 98km/h |
| Chassis | |
| Chassis Model | DFH1180BX1JV |
| Front/Rear Overhang | 1430/2925mm |
| Number of Leaf Springs | 11/11+10,8/10+8,3/4+3,2/3+2 |
| Number of Axles | 2 |
| Wheelbase | 4700,5000,4500mm |
| Axle Load | 4670/8680kg |
| Front Wheel Track | 1815,1855,1900mm |
| Rear Wheel Track | 1800mm |
| Approaching/Departuring Angle | 20/10° |
| Tire | |
| Number of Tires | 6 |
| Tire | 295/80R22.5,10.00R20 18PR,12R22.5 16PR, 12R22.5 18PR,295/60R22.5 18PR,11R22.5 18PR,275/80R22.5 18PR |
| Engine | |
| Model | EQH160-52,EQH160-53,EQH180-52,EQH180-53 |
| Power | 118,118,132,132kW |
| Brand | Dongfeng Trucks Co., Ltd.;Dongfeng Trucks Co., Ltd.;Dongfeng Trucks Co., Ltd.;Dongfeng Trucks Co., Ltd. |
| Displacement | 4752,4752,4752,4752ml |
