Product Details
Basic Information | |
Usage | Vehicle for Special Work |
Fuel Type | Diesel |
Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
Length | 5995mm |
Width | 2300,2400mm |
Height | 2850,3150,3350mm |
Curb Weight | 3600kg |
Gross Weight | 4495kg |
Seats | 3 |
Max Speed | 90km/h |
Chassis | |
Chassis Model | CL3040GDJ |
Front/Rear Overhang | 1450/1145,1450/895,1450/745mm |
Number of Leaf Springs | 8/10+8,9/10+8 |
Number of Axles | 2 |
Wheelbase | 3650,3800,3650,3800,3400mm |
Axle Load | 1800/2695kg |
Front Wheel Track | 1765,1840mm |
Rear Wheel Track | 1750,1800mm |
Approaching/Departuring Angle | 23/18,23/20,23/21° |
Tire | |
Number of Tires | 6 |
Tire | 8.25R16LT 6PR |
Engine | |
Model | YC4EG185-50,YC4EG185-50 |
Power | 136,136kW |
Brand | Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd. |
Displacement | 4730,4730ml |
