Product Details
| Basic Information | |
| Usage | Engineering Vehicle |
| Fuel Type | Diesel |
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length | 10300,9980mm |
| Width | 2550mm |
| Height | 3990mm |
| Curb Weight | 13780kg |
| Gross Weight | 31000kg |
| Seats | 2 |
| Max Speed | 80km/h |
| Chassis | |
| Chassis Model | BJ5319GJBY6GRL-01 |
| Front/Rear Overhang | 1460/2640,1460/2320mm |
| Number of Leaf Springs | left 14 right 13/left 14 right 13/12,left 14 right 13/left 14 right 13/14,13/14/12,3/3/5,10/10/12,13/14/14,11/11/14,10/10/10,3/3/4 |
| Number of Axles | 4 |
| Wheelbase | 2100+2750+1350,2100+3100+1350mm |
| Axle Load | 6500/6500/18000(two axles)kg |
| Front Wheel Track | 2020/2020,2050/2050,2080/2080mm |
| Rear Wheel Track | 1830/1830,1865/1865,1880/1880mm |
| Approaching/Departuring Angle | 20/14° |
| Tire | |
| Number of Tires | 12 |
| Tire | 11.00-20 18PR,11.00-20 16PR,11.00R20 18PR,11.00R20 16PR,12.00-20 18PR,12.00-20 16PR,12.00-20 14PR,12.00R20 18PR,12.00R20 16PR,12.00R20 14PR,12R22.5 18PR,12R22.5 16PR |
| Engine | |
| Model | X11NS6B360,X11NS6B400,X12NS6B360,X12NS6B380,WP8.350E61A |
| Power | 265,294,265,279,257kW |
| Brand | Beijing Foton Cummins Engine Co., Ltd.;Beijing Foton Cummins Engine Co., Ltd.;Beijing Foton Cummins Engine Co., Ltd.;Beijing Foton Cummins Engine Co., Ltd.;Weichai Power Co., Ltd. |
| Displacement | 10500,10500,11800,11800,7800ml |
