Product Details
| Basic Information | |
| Usage | Engineering Vehicle |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards |
| Length | 10050mm |
| Width | 2550mm |
| Height | 3990mm |
| Curb Weight | 13370kg |
| Gross Weight | 31000kg |
| Seats | 2,3 |
| Max Speed | 89km/h |
| Chassis | |
| Chassis Model | CA1312P1K15L3T4BE5A81 |
| Front/Rear Overhang | 1375/2475mm |
| Number of Leaf Springs | 10/10/10,4/4/5,4/4/10 |
| Number of Axles | 4 |
| Wheelbase | 1900+2950+1350mm |
| Axle Load | 6500/6500/18000(two axles)kg |
| Front Wheel Track | 2020/2020,2042/2042mm |
| Rear Wheel Track | 1878/1878,1900/1900mm |
| Approaching/Departuring Angle | 20/° |
| Tire | |
| Number of Tires | 12 |
| Tire | 11.00R20 16PR,12R22.5 16PR,11.00R20 18PR,12R22.5 18PR |
| Engine | |
| Model | WP8.320E51A,WP8.340E51 |
| Power | 235,250kW |
| Brand | Weichai Power Co., Ltd.;Weichai Power Co., Ltd. |
| Displacement | 7800,7800ml |
