Product Details
| Basic Information | |
| Usage | Fire Extinguishing Truck |
| Fuel Type | Diesel |
| Emission Standard | GB3847-2005,GB17691-2005 national Ⅳ emission standards |
| Length | 6870mm |
| Width | 2155mm |
| Height | 3130mm |
| Curb Weight | 6335kg |
| Gross Weight | 9770kg |
| Seats | 3+3 |
| Max Speed | 90km/h |
| Chassis | |
| Chassis Model | DFA1110SJ11D3 |
| Front/Rear Overhang | 1130/1940mm |
| Number of Leaf Springs | 8/10+7,11/9+7 |
| Number of Axles | 2 |
| Wheelbase | 3800mm |
| Axle Load | 2870/6900kg |
| Front Wheel Track | 1770,1831,1740,1845,1769,1903mm |
| Rear Wheel Track | 1640,1586,1610,1680,1629mm |
| Approaching/Departuring Angle | 24/14° |
| Tire | |
| Number of Tires | 6 |
| Tire | 8.25-20 14PR,8.25R20 14PR |
| Engine | |
| Model | ISB3.9-125E40A,CY4102-CE4B,CY4102-CE4C,YC4E140-42,YN38CRD1,YC4S150-48,YC4FA120-40 |
| Power | 92,100,91,103,95,110,88kW |
| Brand | Dongfeng Cummins Engine Co., Ltd.;Dongfeng Chaoyang Diesel Co., Ltd.;Dongfeng Chaoyang Diesel Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.;Kunming Yunnei Power Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd. |
| Displacement | 3900,3856,3856,4260,3760,3767,2982ml |
