Product Details
| Basic Information | |
| Usage | Fire Extinguishing Truck |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 9970mm |
| Width | 2500mm |
| Height | 3800mm |
| Curb Weight | 15150kg |
| Gross Weight | 27800kg |
| Seats | 2+4 |
| Max Speed | 100km/h |
| Chassis | |
| Chassis Model | ZZ5357TXFV464ME5 |
| Front/Rear Overhang | 1500/2470mm |
| Number of Leaf Springs | 4/5,4/12,10/12 |
| Number of Axles | 3 |
| Wheelbase | 4300+1400,4325+1350,4600+1400,4625+1350,5200+1400,5225+1350,5800+1400,5825+1350mm |
| Axle Load | 7010/10400/10390kg |
| Front Wheel Track | 2022mm |
| Rear Wheel Track | 1830/1830mm |
| Approaching/Departuring Angle | 17/12° |
| Tire | |
| Number of Tires | 10 |
| Tire | 385/65R22.5/315/80R22.5,385/65R22.5/12.00R20 |
| Engine | |
| Model | MC11.36-50,MC11.40-50,MC11.44-50,MC13.54-50 |
| Power | 268,297,327,400kW |
| Brand | China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement | 10518,10518,10518,12419ml |
