Product Details
| Basic Information | |
| Usage | Delivery Vehicle |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 5995mm |
| Width | 2130mm |
| Height | 2880mm |
| Curb Weight | 3600kg |
| Gross Weight | 4495kg |
| Seats | 3 |
| Max Speed | 80km/h |
| Chassis | |
| Chassis Model | CA1047P40K50L1BE5A84 |
| Front/Rear Overhang | 1150/1545mm |
| Number of Leaf Springs | 3/4+3,7/7+3,3/7+9,3/7+3,3/3+3 |
| Number of Axles | 2 |
| Wheelbase | 3300mm |
| Axle Load | 1950/2545kg |
| Front Wheel Track | 1510mm |
| Rear Wheel Track | 1475mm |
| Approaching/Departuring Angle | 21/15° |
| Tire | |
| Number of Tires | 6 |
| Tire | 6.50-16,6.50R16,7.00-16,7.00R16 |
| Engine | |
| Model | 4B2-95C50,WP2.1Q95E50,4B2-110C50,WP2.3Q110E50,CA4DC3-12E5-30,WP2.3NQ120E50,WP2.3NQ130E50,CA4DB1-11E5,CA4DB1-13E5 |
| Power | 70,70,80,81,91,88,96,80,95kW |
| Brand | Anhui Quanchai Power Co., Ltd.;Weichai Power Yangzhou Diesel Co., Ltd.;Anhui Quanchai Power Co., Ltd.;Weichai Power Yangzhou Diesel Co., Ltd.;FAW Jiefang Dalian Diesel Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plnat;FAW Jiefang Automobile Co., Ltd. Wuxi Diesel Plnat |
| Displacement | 2545,2088,2545,2290,3000,2290,2290,2200,2210ml |
