Product Details
| Basic Information | |
| Usage | Vehicle for Special Work |
| Fuel Type | Diesel |
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length | 7150,7100mm |
| Width | 2450mm |
| Height | 3350,3150mm |
| Curb Weight | 5000kg |
| Gross Weight | 11950kg |
| Seats | 3 |
| Max Speed | 80km/h |
| Chassis | |
| Chassis Model | EQ1125SJ8CDCWXP |
| Front/Rear Overhang | 1130/1970,1130/2070,1130/2170mm |
| Number of Leaf Springs | 8/10+7 |
| Number of Axles | 2 |
| Wheelbase | 3800,3950,4050mm |
| Axle Load | 4360/7590kg |
| Front Wheel Track | 1755mm |
| Rear Wheel Track | 1586,1650,1800mm |
| Approaching/Departuring Angle | 24.5/13,24.5/12,24.5/11° |
| Tire | |
| Number of Tires | 6 |
| Tire | 245/70R19.5,8.25R20 |
| Engine | |
| Model | YCS04190-68,D25TCIF1,D30TCIF1,D40TCIF1,NV30-C6D,CY4SK261,CY4SK361,YCY30165-60 |
| Power | 140,110,125,135,120,125,125,121kW |
| Brand | Guangxi Yuchai Machinery Co., Ltd.;Kunming Yunnei Power Co., Ltd.;Kunming Yunnei Power Co., Ltd.;Kunming Yunnei Power Co., Ltd.;Dongfeng Chaoyang Diesel Co., Ltd.;Dongfeng Chaoyang Diesel Co., Ltd.;Dongfeng Chaoyang Diesel Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd. |
| Displacement | 4156,2499,2977,4052,2968,3856,3856,2970ml |
