Product Details
| Basic Information | |
| Usage | Suction-type Sewer Scavenger |
| Model | CLW5160GXED4 |
| Gross Weight | 16000 (kg) |
| Volume | 9.15(cubic meter) |
| Rated Load | 7850 (Kg) |
| Curb Weight | 7955 (kg) |
| Dimensions | 8500,8100×2480×3080 (mm) |
| Approaching/Departuring Angle | 20/12,20/13(°) |
| Front/Rear Overhang | 1430/2570,1430/24700(mm) |
| Number of Axles | 2 |
| Wheelbase | 4500,4200(mm) |
| Axle Load | 6000/10000 (kg) |
| Max Speed | 85 (km/h) |
| Chassis type | DFL1160BX4 |
| Number of Tires | 6 |
| Number of Leaf Spring | 8/10+8,7/9+6 |
| Tire | 10.00-20,10.00R20,9.00-20,9.00R20 |
| Front Wheel Track | 1880(mm) |
| Rear Wheel Track | 1860,1800 (mm) |
| Chassis Discharge Standard | GB3847-2005,GB17691-2005 |
| Fuel Type | |
| Engine Model | ISDe210 40, ISDe180 40, ISDe185 40, EQH180-40, ISB180 40 |
| Engine Displacement | 4500 - 6700 (ml) |
| Engine Max Power | 132 - 155 (kw) |
