Product Details
| Basic Information | |
| Usage | Recreational Vehicle |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 9130,8995mm |
| Width | 2550mm |
| Height | 3945mm |
| Curb Weight | 18614kg |
| Gross Weight | 18750kg |
| Seats | 2 |
| Max Speed | 90km/h |
| Chassis | |
| Chassis Model | ND2250FD5J6Z00 |
| Front/Rear Overhang | 1435/2445,1435/2310mm |
| Number of Leaf Springs | 10/13,10/- |
| Number of Axles | 3 |
| Wheelbase | 4450+1450,5050+1450,3800+1450mm |
| Axle Load | 6500/12250(two axles)kg |
| Front Wheel Track | 1995mm |
| Rear Wheel Track | 1800/1800mm |
| Approaching/Departuring Angle | 25/11° |
| Tire | |
| Number of Tires | 10 |
| Tire | 11.00R20 18PR,12.00R20 16PR,315/80R22.5 18PR/315/80R22.5 16PR,12R22.5 18PR |
| Engine | |
| Model | WP10.350E53,WP12.375E50,WP10.310E53 |
| Power | 257,276,228kW |
| Brand | Weichai Power Co., Ltd.;Weichai Power Co., Ltd.;Weichai Power Co., Ltd. |
| Displacement | 9726,11596,9726ml |
