Product Details
| Basic Information | |
| Usage | Refuse Collector |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 8450,8600mm |
| Width | 2550,2500mm |
| Height | 3500mm |
| Curb Weight | 12100kg |
| Gross Weight | 25000kg |
| Seats | 2 |
| Max Speed | 75km/h |
| Chassis | |
| Chassis Model | ZZ3255N3846E1 |
| Front/Rear Overhang | 1550/1750,1550/1900mm |
| Number of Leaf Springs | 10/-,10/12 |
| Number of Axles | 3 |
| Wheelbase | 3800+1350,3775+1400mm |
| Axle Load | 7000/18000(two axles)kg |
| Front Wheel Track | 2022,2041mm |
| Rear Wheel Track | 1830/1830mm |
| Approaching/Departuring Angle | 20/20° |
| Tire | |
| Number of Tires | 10 |
| Tire | 11.00-20,11.00R20,12.00-20 18PR,12.00R20 16PR,12R22.5,315/80R22.5 18PR/315/80R22.5 16PR/315/80R22.5 16PR |
| Engine | |
| Model | D10.31-50,D10.34-50,D10.38-50 |
| Power | 228,249,276kW |
| Brand | China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement | 9726,9726,9726ml |
