Product Details
| Basic Information | |
| Usage | Refuse Collector |
| Fuel Type | Natural gas |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB18285-2005,GB11340-2005 |
| Length | 8545,8675mm |
| Width | 2550,2500mm |
| Height | 3450mm |
| Curb Weight | 12500kg |
| Gross Weight | 25000kg |
| Seats | 2 |
| Max Speed | 80km/h |
| Chassis | |
| Chassis Model | ZZ3257N3847E1L |
| Front/Rear Overhang | 1500/1870,1500/1700mm |
| Number of Leaf Springs | 10/12,10/- |
| Number of Axles | 3 |
| Wheelbase | 3825+1350,3800+1400mm |
| Axle Load | 7000/18000(two axles)kg |
| Front Wheel Track | 2022,2041mm |
| Rear Wheel Track | 1830/1830mm |
| Approaching/Departuring Angle | 19/18° |
| Tire | |
| Number of Tires | 10 |
| Tire | 315/80R22.5 18PR/315/80R22.5 16PR,12.00R20 16PR,11.00R20,12.00-20 18PR,11.00-20 |
| Engine | |
| Model | T10.32-50,T10.34-50,T12.34-50,T12.38-50 |
| Power | 235,250,249,279kW |
| Brand | China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement | 9726,9726,11596,11596ml |
