Product Details
| Basic Information | |
| Usage | Street Sprinkler |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 7830mm |
| Width | 2500mm |
| Height | 3200mm |
| Curb Weight | 5800kg |
| Gross Weight | 15800kg |
| Seats | 3 |
| Max Speed | 90km/h |
| Chassis | |
| Chassis Model | EQ1160GD5DJ1 |
| Front/Rear Overhang | 1450/2430,1250/2080,1450/1880mm |
| Number of Leaf Springs | 8/9+7,8/10+7,3/4+3 |
| Number of Axles | 2 |
| Wheelbase | 3650,3800,3950,4200,4400,4500,5100mm |
| Axle Load | 5800/10000kg |
| Front Wheel Track | 1810,1940,1750mm |
| Rear Wheel Track | 1800,1860,1700,1830mm |
| Approaching/Departuring Angle | 23/12,23/10,23/8° |
| Tire | |
| Number of Tires | 6 |
| Tire | 9.00-20 16PR,10.00-20 16PR,10.00R20 16PR,295/80R22.5 18PR |
| Engine | |
| Model | EQH160-52,ISD180 50,YC4E140-56,YC4E160-56,YC4EG140-50,YC4FA130-50,YC4S150-50,ISB180 50,WP3.7Q140E50,WP4.1Q160E50 |
| Power | 118,132,103,118,105,95,110,132,103,115kW |
| Brand | Dongfeng Trucks Co., Ltd.;Dongfeng Cummins Engine Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.; Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.; Guangxi Yuchai Machinery Co., Ltd.;Guangxi Yuchai Machinery Co., Ltd.;Dongfeng Cummins Engine Co., Ltd.; Weichai Power Yangzhou Diesel Engine Co., Ltd.;Weichai Power Yangzhou Diesel Engine Co., Ltd. |
| Displacement | 4752,4500,4260,4260,4730,2982,2600,5900,3660,4088ml |
