Product Details
| Basic Information | |
| Usage | Engineering Vehicle |
| Fuel Type | Diesel |
| Emission Standard | GB17691-2005 national Ⅴ emission standards, GB3847-2005 |
| Length | 9970,10320mm |
| Width | 2550mm |
| Height | 3990mm |
| Curb Weight | 14200kg |
| Gross Weight | 31000kg |
| Seats | 2 |
| Max Speed | 82km/h |
| Chassis | |
| Chassis Model | ZZ1313N306GE1 |
| Front/Rear Overhang | 1500/2270,1500/2620,1500/2245,1500/2595mm |
| Number of Leaf Springs | 11/11/10,3/3/4,3/3/5,11/11/4,11/11/5 |
| Number of Axles | 4 |
| Wheelbase | 1800+3025+1400,1800+3050+1350mm |
| Axle Load | 6500/7000/17500(two axles)kg |
| Front Wheel Track | 2035/2035mm |
| Rear Wheel Track | 1850/1850mm |
| Approaching/Departuring Angle | 14/14° |
| Tire | |
| Number of Tires | 12 |
| Tire | 12R22.5,11.00R20 |
| Engine | |
| Model | MC07.31-50,MC07.34-50,MC07.34-52 |
| Power | 228,248,248kW |
| Brand | China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd.;China National Heavy Duty Truck Group Co., Ltd. |
| Displacement | 6870,6870,6870ml |
