Product Details
| Basic Information | |
| Usage | Delivery Vehicle |
| Fuel Type | Diesel |
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length | 10130mm |
| Width | 2550mm |
| Height | 4000,3900mm |
| Curb Weight | 15600kg |
| Gross Weight | 31000kg |
| Seats | 2 |
| Max Speed | 80km/h |
| Chassis | |
| Chassis Model | CQ1317HL6Z |
| Front/Rear Overhang | 1435/2095mm |
| Number of Leaf Springs | 3/3/6,8/8/12,9/9/12,10/10/12,3/3/12 |
| Number of Axles | 4 |
| Wheelbase | 2000+2800+1400,2000+3000+1400,2000+4000+1400,2000+3200+1400,2150+4250+1400mm |
| Axle Load | 6500/6500/18000(two axles)kg |
| Front Wheel Track | 2020/2020,2040/2040,2060/2060mm |
| Rear Wheel Track | 1858/1858mm |
| Approaching/Departuring Angle | 16/13° |
| Tire | |
| Number of Tires | 12 |
| Tire | 12R22.5 18PR,315/80R22.5 18PR,11.00R20 18PR,12.00R20 18PR,295/80R22.5 18PR,315/60R22.5 20PR |
| Engine | |
| Model | SC10E400Q6,SC10E330Q6,SC10E370Q6,SC10E300Q6,SC10E420Q6,F2CCE611G*M,F2CCE611H*M,F2CCE611J*M,F2CCE611K*M |
| Power | 294,243,272,221,309,287,263,243,215kW |
| Brand | Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.;Shanghai Diesel Engine Co., Ltd.; Saic Fiat Powertrain Hongyan Co., Ltd.;Saic Fiat Powertrain Hongyan Co., Ltd.;Saic Fiat Powertrain Hongyan Co., Ltd.;Saic Fiat Powertrain Hongyan Co., Ltd. |
| Displacement | 10420,10420,10420,10420,10420,8709,8709,8709,8709ml |
