Product Details
| Basic Information | |
| Usage | Multi-purpose Dust Suppression Truck |
| Fuel Type | Diesel |
| Emission Standard | GB3847-2005,GB17691-2018 national Ⅵ emission standards |
| Length | 11382mm |
| Width | 2545mm |
| Height | 3760mm |
| Curb Weight | 12805kg |
| Gross Weight | 25000kg |
| Seats | 2,3 |
| Max Speed | 89km/h |
| Chassis | |
| Chassis Model | DFH1250D4 |
| Front/Rear Overhang | 1480/3007mm |
| Number of Leaf Springs | 3/10,3/4,9/10 |
| Number of Axles | 3 |
| Wheelbase | 4350+1350,5350+1350,5700+1350,4600+1350,4800+1350mm |
| Axle Load | 7000/18000(two axles)kg |
| Front Wheel Track | 2010,2040,2070mm |
| Rear Wheel Track | 1860/1860,1880/1880mm |
| Approaching/Departuring Angle | 15/9° |
| Tire | |
| Number of Tires | 10 |
| Tire | 295/80R22.5 18PR,11.00R20 18PR |
| Engine | |
| Model | D6.7NS6B290,DDi75E350-60,DDi75E300-60 |
| Power | 213,257,220kW |
| Brand | Dongfeng Cummins Engine Co., Ltd.;Dongfeng Trucks Co., Ltd.;Dongfeng Trucks Co., Ltd. |
| Displacement | 6700,7500,7500ml |
